EL7-RS7500PT
R16,367.67 incl. VAT
Leadshine EL7-RS Series AC Servo Drive – 7.5 kW
In stock
Add to wishlistAdded to wishlist0
Add to compareAdded to compare0
SKU: OAP-DRV-0014
Leadshine EL7-RS Series AC Servo Drive – 7.5 kW
The EL7-RS Series is a next-generation mid-range AC servo drive and motor line developed by Leadshine Technology Co., Ltd.
Engineered for cost-effectiveness without sacrificing performance, the EL7-RS delivers advanced functionality and precise control for a wide range of industrial applications.
Key Features
- Power Range: 750 W – 7.5 kW (model shown: 7.5 kW)
- Control Modes: Position, velocity, torque, and hybrid loop control
- Communication: Supports Modbus, plus analogue and pulse + direction inputs
- Servo Tuning: One-click or single-parameter auto-tuning for fast setup
- Advanced Functions:
- Zero Tracking Control (ZTC)
- Vibration suppression (mechanical resonance & end vibration)
- Friction compensation
- 16 configurable PR motion paths
I/O & Performance
- User-Configurable I/O: 8 DI, 5 DO, 2 AI, 1 AO
- Pulse Input: High-speed 4 MHz; low-speed 200 kHz (24 V) / 500 kHz (5 V)
- Energy Management: Built-in regenerative resistor
Motor Compatibility
- Pairs with Leadshine AC servo motors rated 50 W – 7.5 kW
- Motors feature 23-bit magnetic or optical encoders for exceptional positioning accuracy
- Optional holding brake available
Technical Specifications:
| Model | EL7-RS7500P |
| Input Voltage | 400VAC 3ph |
| Rated Power  (W) | 7500 |
| Rated Current (Arms) | 25.7 |
| Peak Current (Arms) | 63.6 |
| Command Source | Modbus  RTU/Pulse+Direction/Analogue |
| # of Digital  Inputs | 8 |
| # of Digital  Outputs | 5 |
| # of Analogue Inputs | 2 |
| # of Analogue Outputs | 1 |
